    360°Manual Search EO Ir Imaging Systems HD Image Display And Fog Penetration

    Ask Lasest Price
    Brand Name : HEOS
    Model Number : HITV(-d)
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    360°Manual Search EO Ir Imaging Systems HD Image Display And Fog Penetration

    360°Manual Search EO Ir Imaging Systems HD Image Display And Fog Penetration


    Characteristics

    • Applicable for vehicles, ships, land base and subcamp etc. areas.

    • All weather and all dimensional search, reconnaissance and surveillance for the ships, aircraft, personnel etc. targets within a certain range of the ship.

    • 360°manual search, automatics scan, manual capture and automatic tracking target

    • HD image display and fog penetration

    • Real-time image record, which is cable to display and record date and time, azimuth, geographic location of the target etc.

    • Failure detection and failure location

    • VxWorks military operation system is applicable.


    Main technical specification
    TV sensorCameraHD 3 megapixel CCD
    Lens20~750mm HD fog penetration
    IR sensorWaveband8μm~14μm
    DetectorUncooled 320×256 (or 640×480)
    Lens44/132mm
    Operating distanceDiscovery distance (Daytime)≥22KM
    Discovery distance (Night)≥10KM
    Recognition distance (Daytime)≥15KM
    Recognition distance (Night)≥8KM
    Tracking accuracyAzimuth≤0.3mrad
    Elevation≤0.3mrad
    Servo capabilitySpeed60°/s
    Acceleration150°/s
    Operating rangeAzimuth+175°or 360°continuous rotation
    Elevation-60°~+80° adjustable
    DirectorTurning radius≤260mm
    Height≤660mm
    Weight≤65kg
    Display and control deviceWeight≤50kg
    Complete machinePower600W
    Record time≥1000h
    Optional sensorLaser illuminator810nm wave length, power ≥15W
    Laser dazzler532nm wave length, power is adjustable between 0~2W
    Laser range finderRange is between 140m-10km, accuracy is ±5m
